Automatic Horizontal Balers

About Automatic Horizontal Balers

With a processing power of up to 15 tonnes per hour and require minimal human interaction providing high efficiency and safety for those working with the baler.

High capacity

Fully automatic balers provide a high capacity while the man hour consumption remains at the lowest possible level.

Continuous feeding

A fully automatic horizontal baler system enables continuous feeding of waste material. The excess of material in the pressing chamber gets cut off by a strong knife.

Compact design

The hydraulic cylinders driving a strong press plunger are located along the side walls of the machine. This design provides a minimal length of the machine and at the same time a high compaction force, large pressing chamber and fast pressing cycle.

Density control

Automatic density control ensures shapely and evenly compressed bales with highest possible weight.

Handling

The bale slides at the end of the pressure channel enable easy access to pick up the finished bales.

Ease of use

Intuitive controls allow for change of settings and parameters on the machine depending on status.


Automatic Horizontal Balers we Offer

We offer a range of balers to suit your requirements.

Choosing a Baler

Choosing a baler is based on a number of factors:

  • Space available
  • Volume processed
  • Collection rate

The best way to choose the right option for your needs is to get in touch and we can best advise.

An example of cardboard bales stacked on top of each other. Bales can be stacked up to three high to save space.
An example of cardboard bales stacked on top of each other. Bales can be stacked up to three high to save space.

Call, email or enquire via our free waste audit form to contact a waste specialist from Waste Handling Solutions to find out more or arrange a free waste audit.

A pair of mill balers in-situ.

Cardboard & Plastic Balers

A automatic horizontal baler can handle both plastic or cardboard allowing you flexibility with your waste recycling.

Cardboard Bale being ejected from the baler

Cardboard Balers

A automatic baler is a perfect fit for businesses producing 15-20 tonne of cardboard a week.

A full automatic baler can hold a bale and an additional three bales can be stacked for collecting.

How much cardboard do I need to produce?

If you are producing 15-20 tonnes of cardboard then a baler can be more economical.

Plastic Bale preparing to be ejected from the baler

Plastic Balers

A automatic baler is a perfect fit for businesses producing 15-20 tonne of plastic a week.

A full automatic baler can hold a bale and an additional three bales can be stacked for collecting.

How much plastic do I need to produce?

If you are producing 15-20 tonnes of plastic then a baler can be more economical.

Call, email or enquire via our free waste audit form to contact a waste specialist from Waste Handling Solutions to find out more or arrange a free waste audit.

Technical Information

Baler FootprintFloor Space4㎡
Equivalent4x wheelie bins
Accepted MaterialSoft Plastic
Paper
Cardboard
Bale SizeWidth1,150mm
Height750mm
Depth750-1,110mm
TransportBales FitFlat bed lorry
WeightBale Weightup to 1,000kg
Cycle Time49 / 34 Seconds
Fill OpeningsWidth1,400-2,000mm
Height1,020mm
Power3 Phase 380/400 V 7.5 kW motor
Capacity1.5 to 20 tonne per hour
Noise~80 dB

Fully Automatic Horizontal Baler Installation

We can assist with delivery and installation of both new, refurbished and rental machines. Our experience and expertise can deliver and install balers in even the toughest of circumstances in any location nationwide.

Baler being craned into an industrial unit to be installed.
Baler being craned into an industrial unit to be installed.
A baler being craned off a flat bed lorry for installation.
A baler being craned off a flat bed lorry for installation.

Call, email or enquire via our free waste audit form to contact a waste specialist from Waste Handling Solutions to find out more or arrange a free waste audit.
